    70 KW/Day HDPE Blow Molding Machine

    Ask Lasest Price
    Brand Name : Sanqing
    Model Number : SQ-6
    Certification : CE ISO9001
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets/month
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    70 KW/Day HDPE Blow Molding Machine

    Product Name

    HDPE LDPE Plastic Bottle Making Machine Pakistan Bangladesh, Mango, Grape, Strawberry Shapes Blow Molding Machine


    Product Description

    Servo Motor Six Stations Blow Molding Machine is our top rank machine, which could produce bottles under 5 Liters with very high speed. Every 5 seconds could produce one piece of bottle. The output is equal to 3 sets of the normal double stations machine.
    With the high production performance, the power consumption is very low, it is uses servo motor to open and close molds, the electricity is directly convert to the action, no need hydraulic power for this process.
    Save mold cost is another feature, all six stations deflashing is done after bottle blowed, all the bottles will be deflashed by the deflashing device after conveyor.
    This is the first rotary servo machine designed around the world. It is the fastest machine so far.
    Item
    Parameters
    Production Volume
    Max. 5L
    Production
    Capacity
    17000 PCS/24 Hrs.
    Power
    Consumption
    70KW/Day
    No. of Die Head
    Single
    Screw Dia.
    110mm
    Average Power
    70 KW
    Clamping Force
    5 Ton
    Template Size
    350X400mm
    Servo Motor
    Mitsubishi Brand
    PLC System
    Mitsubishi Brand
    Parison Controller
    MOOG Brand
    Motor
    Siemenz
    Air Cylinder
    SMC
