    6 Station Automatic Bottle Making Machine 1.5kw Blow Molding Equipment 1000pcs/H

    Ask Lasest Price
    Brand Name : Sanqing
    Model Number : SQ-6
    Certification : CE ISO9001
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets/month
    Delivery Time : 45 days
    • Product Details
    • Company Profile

    6 Station Automatic Bottle Making Machine 1.5kw Blow Molding Equipment 1000pcs/H

    Product Name
    Automatic Bottle Making Machine, Ice Lolly Tube Bottle for Juice Blowing Molding Machine
    Product Description

    factory supply ice lolly ice pop ice tube ice stick ice candy bottles blowing machine

    this machine adopts screw extrusion blow molding process it is controlled by PLC (computer), high precision. It is specially designed for LDPE Ice lolly tube,fruit shape bottle,dropper pipette bottle,toy shape or soft bottle,HDPE milk bottle,yoghurt bottle etc. The machine has awarded CE Certification.

    Easy to operate, high speed to improve production efficiency and lower the production cost, reduce the labor, less Maintain, easy to clean, lower Noisy,Longer Life

    it also suitable to make the HDPE/PP cutting mouth bottle,max.volume is 1000ml

    it also can be 1-6 cavity in one mold depending on the sample

    this machine is first developed by sanqing, also is patented machine, save energy

    In case customer needs different weight of product, our machine have device to adjust weight follow customer requirement.

    Our rotational machine is the fastest machine to produce LDPE products, because our machines are using 4 molds, 6 molds, 8 molds, 10 molds, 12 molds to produce at the same time. The production capacity of 6 molds machine could reach 3000 pieces per hour.


    We provide different level of price to cater customer demand, we have connected type(extruder and blower), separate type(extruder and blower not connected), full automatic type, semi-automatic type of machines. We also have devices to de-flashing the waste part of bottle.

    Parameter

    Model

    Parameters

    4 work station6 work station8 work station
    Max. Volume of Bottle(ml)100015001500
    Max. Dia. Of Bottle(cm)71010
    Productive capacity(pcs/hour)500-70001000-80001500-8000
    Mould Size (L, W, H) (mm)118x120x350118x120x350118x120x350
    Motor Power(KW)0.751.11.5
    Air Consumption(m3/Min)0.4
    Product Weight(KG/Hour)4008001000
    Dimension(L, W, H)(mm)1400x1000x14001600x1200x15001900x1700x1400
    Applicable Raw MaterialPE, PP, PVC
    Speed regulating methodFrequency control of motor speed
